My Electric Motorcycle Project
I am converting a gas-powered motorcycle into a battery-electric motorcycle. This blog is for the recording and sharing of ideas, questions, lessons, information, and progress during my project.
Monday, August 19, 2013
Saturday, August 10, 2013
Usage Stats
I have more stats:
1.01 kW for 9.0 kilometers (estimated average of 35 mph round trip to work, 2013.08.09)
1.6 kW for 20.3 kilometers (estimated average of 30 mph)
.89 kW for 12.5K (estimated average of 15 mph)
This goes a bit beyond me at the moment as nothing is a constant rate. That is to say that I don't charge or discharge the batteries at a constant rate.
What I do know is that I pay $0.108051 per kWh.
I may be simplifying this too much, but at first glance, that means my round trip to work costs me 11 cents.
Meanwhile, assuming 17 mpg over the same round trip (5.6 miles) yields .3294117 gallons consumed. With each gallon of premium at $3.80, that third of a gallon costs me over $1.25.
I could save $1.14 daily. After a week, that's $5.70. That's lunch, man!
Given, this is an small electric motorcycle versus a sports car. But it does encourage me to take the bike as often as possible.
By the way, I think 20 kilometers is my absolute max range. I had doubts I was going to make it home toward the end of that trip. I was moving, but I had no get up and go. Good thing work has a charger!
-Colby
Tuesday, July 23, 2013
Power Usage
Finally, I'm at a point where I can determine inputs and outputs.
I have a means to measure how much power goes into the bike. That is by way of the Kill-A-Watt.
I'll update this post in the future, but for now, I wish to document that from a 60% depth of discharge, 1.6 KW were used re-charging the bike. That's about the only stat I have.
I guess I should now keep a log of distance traveled and power spent recharging there-after to gather up data. From that I can determine the trend and I have some idea. I'll try to share as I go.
-Colby
I have a means to measure how much power goes into the bike. That is by way of the Kill-A-Watt.
I'll update this post in the future, but for now, I wish to document that from a 60% depth of discharge, 1.6 KW were used re-charging the bike. That's about the only stat I have.
I guess I should now keep a log of distance traveled and power spent recharging there-after to gather up data. From that I can determine the trend and I have some idea. I'll try to share as I go.
-Colby
Monday, March 25, 2013
Mileage
I think I started last week with around 435 km on the odometer. I did a test ride Saturday afternoon, rode to church on Sunday, rode to work every day except Friday, and rode Saturday morning. I ended the week at 510 km.
I didn't realize I'd ridden it so little in the past three years, to have only accumulated 270 miles. I'm enjoying putting some real mileage on it now.
75km is about 46.6 miles.
My 350Z averages 17 miles/gallon of premium in the city.
46.6 miles / 17 mpg = 2.7 gallons
2.7 gallons * $3.50 a gallon = $9.59 I would have spent on premium gasoline last week.
How much I spent on electricity because of the bike last week is another question I'd like to answer. Since my employer is giving me fuel for free, it's not much.
-Colby
I didn't realize I'd ridden it so little in the past three years, to have only accumulated 270 miles. I'm enjoying putting some real mileage on it now.
75km is about 46.6 miles.
My 350Z averages 17 miles/gallon of premium in the city.
46.6 miles / 17 mpg = 2.7 gallons
2.7 gallons * $3.50 a gallon = $9.59 I would have spent on premium gasoline last week.
How much I spent on electricity because of the bike last week is another question I'd like to answer. Since my employer is giving me fuel for free, it's not much.
-Colby
Saturday, March 16, 2013
Overall Status
I wasn't able to get the bike ready and safe to ride on Friday. Here are recent pictures:
Chain isn't installed in these pictures, but that's done now. Rear reflector, a bit more inspecting and then I can start test riding it a bit.
-Colby
Chain isn't installed in these pictures, but that's done now. Rear reflector, a bit more inspecting and then I can start test riding it a bit.
-Colby
Sunday, March 10, 2013
Turn Signal Circuits
I finally finished wiring up the turn signals. The rear ones are new, so no big deal. The front ones are not new, but used numerous connectors and different colored wires for just two simple circuits. I cleaned all that up, and in the process, found a really confounding and interesting issue.
After wiring everything up, I found all four turn signals blinked together when I signaled left or right. Furthermore, I have a single turn-signal indicator bulb in the dash. It is supposed to be lit when either the left or right signal is active. The indicator bulb in the dash did not appear to light at all (it was lit but extremely dim). This perplexed me for hours. I diagnosed all I could, but all the while, I knew I'd been careful not to alter any circuits in the harness re-work. Plus, there is a "winker" module involved which makes it difficult to absolutely figure out because it is a black box to me. In the end, my Dad and I worked out that the circuit for the indicator bulb in the dash must have been designed only with incandescent turn signals bulbs in mind. Something about all the turn signals using LEDs changed the behavior of the module or removed a circuit this indicator relied on.
For now, I have removed the indicator. The winker module beeps so loud, the dash-bulb is pointless anyway. The LED turn signals blink correctly and at their normal speed. Perhaps when I diagram the entire wiring harness (should have already done that), I'll figure out what exactly caused it and maybe a way to keep the indicator bulb.
I'm charging the batteries now, so that leaves...
After wiring everything up, I found all four turn signals blinked together when I signaled left or right. Furthermore, I have a single turn-signal indicator bulb in the dash. It is supposed to be lit when either the left or right signal is active. The indicator bulb in the dash did not appear to light at all (it was lit but extremely dim). This perplexed me for hours. I diagnosed all I could, but all the while, I knew I'd been careful not to alter any circuits in the harness re-work. Plus, there is a "winker" module involved which makes it difficult to absolutely figure out because it is a black box to me. In the end, my Dad and I worked out that the circuit for the indicator bulb in the dash must have been designed only with incandescent turn signals bulbs in mind. Something about all the turn signals using LEDs changed the behavior of the module or removed a circuit this indicator relied on.
For now, I have removed the indicator. The winker module beeps so loud, the dash-bulb is pointless anyway. The LED turn signals blink correctly and at their normal speed. Perhaps when I diagram the entire wiring harness (should have already done that), I'll figure out what exactly caused it and maybe a way to keep the indicator bulb.
I'm charging the batteries now, so that leaves...
- final coats of paint to tail light panel
- adjust winker module mounting
- Clean sprockets / chain
- Full road-worthiness inspection, test ride
One a day and I can ride on Friday. =)
-Colby
Saturday, March 9, 2013
Tail Light Fabrication (5/5)
Lots of mud and lots of sanding produced this:
Several primer coats and more sanding:
Also accomplished a few other things recently.
Several primer coats and more sanding:
Also accomplished a few other things recently.
- tested out wiring harness for the first time since the re-work.
- Added tail lights to wiring harness.
- made plastic washers for new tail light panel.
- Adjusted license plate bracket
I'm on a 3 phase plan now.
- Get the bike running and start riding it to work
- Install chargers so I can charge while at work
- Install retractable extension cord
Todo for phase 1:
- charge batteries
- add final coats of paint to tail light panel
- finish re-wiring front blinkers
- adjust winker module mounting
- Clean sprockets / chain
- Full road-worthiness inspection, test ride
